ES Replacement System F.A.Q.
What Taylor guitars will it work with?
ES1.1: 2003-2006, AA Battery Box
Yes, with our AA Adapter kit.
Because of the age of the guitar and variations in Taylor's manufacturing, the Saddle-Pickup may need adjustment for a correct setup. You can purchase our Saddle Customization option, and we will pre-shape the Saddle-Pickup according to the dimensions on your current saddle.
ES1.2: 2007-2009, 9V Battery Box, Fused String Ground
Yes, our system will fit.
Because of the age of the guitar and variations in Taylor's manufacturing, the Saddle-Pickup may need adjustment for a correct setup. You can purchase our Saddle Customization option, and we will pre-shape the Saddle-Pickup according to the dimensions on your current saddle.
ES1.3: 2010-2013: 9V Battery Box, Fused String Ground
Yes, our system will fit.
As long as the original saddle hasn't been altered for action adjustments, installing our Saddle-Pickup will maintain the guitar's current action.
ES2: 2014+, 9V Battery Box
Yes, our system will fit.
As long as the original saddle hasn't been altered for action adjustments, installing our Saddle-Pickup will maintain the guitar's current action.
ES-T
Yes, our system will fit.
ES-N
Yes, our system will fit.
ESB1.1
No, our system will not fit.
ESB1.2
No, our system will not fit.
Fishman Prefix and Prefix Plus
No, our system will not fit.
Fishman Prefix Pro, Prefix Pro Blend, Prefix Stereo Blender
Our PreSonic pickup system with the small bracket size is a direct replacement.
Does the guitar need an action setup after installing the pickup system?
See the above F.A.Q. for notes on your specific guitar.
In general, if the original saddle has not been altered to adjust the action, then installing our system will maintain the guitar's current action.
What if I want to adjust the action?
We recommend following the official Taylor action adjustment procedure. This can be done at an authorized Taylor service center and is free for the original owner of the guitar.
This procedure involves adjusting the neck angle with shims and does not touch the saddle.
